Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting

Name: Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting
Brand: Anping County Chant Wire Mesh Manufacturing Co.,Ltd
SKU: QT-C-1010
Price: 5.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: QIANTE

Certification: CE

Model Number: QT-C-1010

Payment & Shipping Terms

Minimum Order Quantity: 5 m2

Price: Usd 9-28 /m2

Packaging Details: Wooden Case

Delivery Time: 5-8 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 8000m2/week

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                Ferruled Rope Zoo Wire Mesh, Stainless Steel Flexible Wire Mesh Netting


Name:	Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting	Material:	Sus304 316 316L
Type::	Woven And Ferrule	Wire Thickness:	From 1.2 Mm To 6.0 Mm
Cable Structures:	77 719	Finished:	Ultrasonic Bath / Black Oxide
Application:	Construction Wire Mesh, Protecting Mesh, Screen, Decorative Mesh, Fence Mesh, Cages, Bagpack Protector, Drop Preventing Net	Aperture:	2525-300300mm

Name:	Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting
Material:	Sus304 316 316L
Type::	Woven And Ferrule
Wire Thickness:	From 1.2 Mm To 6.0 Mm
Cable Structures:	77 719
Finished:	Ultrasonic Bath / Black Oxide
Application:	Construction Wire Mesh, Protecting Mesh, Screen, Decorative Mesh, Fence Mesh, Cages, Bagpack Protector, Drop Preventing Net
Aperture:	2525-300300mm

Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting

Product Description

The rope mesh material is Stainless steel 304 316 304L 316L.
Wire structure common size: 7x7-the diameter is < 3mm,7x19>3mm.

Stainless steel rope mesh specification

Wire rope diameter	1.2mm,1.5mm,2.0mm,2.5mm,3.0mm,3.2mm,4.0mm
Mesh hole	3x3cm,4x4cm,5x5cm,6x6cm,7x7cm,8x8cm etc.

Don't understand how to mark the mesh size,let us use one drawing mark it. Common opening angle is 600,900.

1. Material of Stainless Steel Zoo Wire Mesh : Stainless steel 304,304L,316,306L etc.

SS304	(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316	(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0

Recommended Monkey Enclosure Zoo Wire Mesh:

Material	Cable Diameter	Hole Size	Normal Break
SS304/316/316L	3/32" (2.4MM)	2.5" x 2.5"	920 LBS
SS304/316/316L	3/32" (2.4MM)	2" x 2"	920 LBS
SS304/316/316L	5/64" (2.0MM)	2.5" x 2.5"	676 LBS
SS304/316/316L	5/64" (2.0MM)	2" x 2"	676 LBS
SS304/316/316L	1/8" (3.2MM)	2" x 2"	1600 LBS
SS304/316/316L	1/8" (3.2MM)	3" x 3"	1600 LBS

Stainless steel zoo wire is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of the mesh can even stand up to heavy loads.
Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting 0

Feature of Zoo Wire Mesh :

Flexible, elegant, discreet, filigreed, multifunctional.
Light weight, easy to install.
Corrosion resistant, air good liquidly.
Total pro-environment, recyclable, no toxic.
No need special coating and cleaning.

Application

Stainless steel rope mesh products with modern and safety features have flexible structural design, lower construction and maintenance cost. Our products are widely used in the field of protection & safety, greenery, zoo fencing, bird aviary, sports & leisure, etc. Our services have covered more than 600 different projects worldwide.

Ferruled Rope Zoo Wire Mesh , Stainless Steel Flexible Wire Mesh Netting 2
